The new ICE Raptor Carbon BMX racing frame is one of the hottest frames out! It features their IRC ‘’Ice Roller Coaster’’ chain tensioning system and rear Ø15mm thru-axle. It also features a unique ‘’ARCH’’-type rear stays which really make it stick out from the rest. The matte grey and sand colorway gives the Raptor a classy, elite look. Riders have already been racking up podium finishes on this bike and they have a sick booth setup at the UCI Worlds this week.
This ICE ‘’RAPTOR’’ frame is made from best quality Toray T700 + T800 carbon fiber (T800 used for reinforcement). Not many brands use the T800….
Frame is molded in 2 parts and then stuck during making.
Glue used is a high-quality American glue named 9432
According to the forces to which a BMX Race frame is subjected, local reinforcement must be carried out. EPS moulding technology allows us to go even further in reinforcement and finishing when manufacturing our RAPTOR frames.
3D technology is used for the design of these EPS . We use finishing EPS which are then wrapped in LATEX, allowing an optimal modling of the fiber avoiding any overlapping of it and making the internal structure of our frames perfectly wrinkled . This way fiber is perfectly oriented, transition of angles is smooth, avoiding any concentration of stresses on a specific point.This is why our frames are reliable, resulting from an optimal design .
‘’ARCH’’-type rear stays designed to be uses with a rear disc-brake caliper in Flatmount standard, which makes everything very discrete and classy. This system allows a Ø140mm brake rotor.
Rear dropouts designed for a mounting with a rear Ø15mm thru-axle (Ø 15mm axle delivered with frameset ) or 10mm axle (adapters also delivered with frameset).
